* The purchaser shall at it's own costs be responsible for disconnecting, dismantling and removing items purchased from the auction location. If the purchaser is intending to export items purchased at the auction it shall be responsible at its own cost for ensuring compliance with all UK export conditions and the obtaining of any applicable Export Licences.
* Please note all dimensions stated are approximate, however the accuracy cannot be guaranteed and should be verified by the bidder before bidding.
The specifications given are to the best knowledge of the auctioneer. However, the accuracy is not guaranteed and should be verified by the buyer prior to bidding.
X Axis Travel - 762mm
Y Axis Travel - 510mm
Z Axis Travel - 510mm
Maximum Size - 950 x 520mm
T Slots - 3 x 18mm
Maximum Table Load - 455Kg
Spindle C/Line to Column - 524
Spindle Nose to Table Surface - 127mm/637mm
Rapids X/Y/Z - 16m/min.
Programme Feed Rates 3 – 12m/min.
Spindle Power - 5.5kW
Spindle Speeds - 60 – 6,000rpm
ATC Bi-Directional - 21 Station
Maximum Tool Weight- 6.8Kg
Maximum Tool Diameter - 80mm
Maximum Tool Length - 305mm
Tool Change Metal to Metal - 8 Seconds
